Working table: Length 680 mmWidth 450 mmMax. dimensions of work piece: Length 1000 mmWidth 550 mmHeight 220 mmTable load max. 750 kgLongitudinal traverse (X-axis) 350 mmCross traverse (Y-axis) 220 mmVertical travel (Z axis) 220 mmTaper-cut +/- 30 °Diameter of electrode wire: from 0.33 mmup to 0.10 mmMax. cutting speed with wire 0.33 mm 400 mm2/minTotal power required 10 kVADielectric aggregate: Contents 760 lAir connect 6 - 7 barVoltage 50 Hz 3x 400 VoltTotal power required 12 kVAWeight total installation approx. 2100 kgOverall dimensions machine: Length 2050 mmWidth 2020 mm

    Height 2000 mm
